MQS Dry Grinding Grate Ball Mill Machine

• Product Details

Dry Grinding Grate Ball Mill is an efficient tool for grinding many materials into fine powder(generally used to grind material 1/4 inch and finer, down to the particle size of 20 to 75 microns). It is widely used inbuilding material, chemical industry, etc.

Dry Grinding Grate Ball Mill is the key equipment for grinding after the crushing process, which is widely used in the manufacturing industry, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics and can be used for the dry and wet grinding for all kinds of ores and other grindable materials.

 The main part of Dry Grinding Grate Ball Mill is a shell which is assembled on the bearing with low revolution speed. This ball mill is driven by motor through reducer and surrounding gear which can reduce the speed. Or this ball mill can be driven by synchronous motor with low speed. After gear reduces the speed, transmission assembly can rotate. There are many grinding mediums-ball- in the ball mill. Grinding mediums can be lifted to the certain height, and then thrown down or drain off under the effect of centrifugal force and friction. The materials are continuously feed into the shell, and then crushed by moving grinding medium, at last the product can be discharged by the force of overflow and continuously feeding. All the materials can go to the next process.

Performance Parameter Table of Dry Grinding Grate Ball Mill

Weight of Each Parts（kg）


 The structure of Dry Grinding Grate Ball Mill：
 The machine is composed by feeding part, discharging part, rotation part and driving part (reducer, small driving gear, electric motor and electric control). The quill shaft adopts cast steel part and the liner is detachable. The rotation big gearwheel is made by cast hobbling processing and the drum is equipped with wear-resistant liner, which has good wear-resistance. The machine is with stable and reliable working condition.

Working principle of Dry Grinding Grate Ball Mill
 Dry Grinding Grate Ball Mill is horizontal cylindrical rotation device, driven by brim gearwheel. There are two chambers and grid. Material goes into the first chamber through the feeding inlet. Inside the first chamber, there are stage liners and ripple liners as well as steel balls. The shell rotates so as to generate electricity, and this force brings ball to a certain height and then balls drop down by gravity, the impact is the grinding force to the material. After the primary grinding, materials go into the second chamber through segregate screen. In the second chamber, there are flat liners and steel ball, after the secondary grinding, material is discharged from the discharging.

Features of Dry Grinding Grate Ball Mill:
 1.Most professional ball mill
 2.Energy-Saving about 20%~35%.
 3.Stable performance
 4.Most Competitive Price

The installation of MQ ball mill
 Ball mill should be installed on a solid concrete foundation. Ball mill on the basis of design and construction of see ball mill assembly diagrams and foundation drawing. In order to guarantee the position accuracy of ball mill parts in use process does not have big change, ball mill on the basis of the whole structure should be adopted.

Concrete foundation compressive strength after reaching more than 75% can be installed on ball mill. Before installing response of quality inspection, the defects of the strength of concrete has no effect, the number of the reserved hole position and meets the requirements, the reserved hole clutter and without water, without pollution. By using "ground", when installation, on the surface should be embedded based on "center the board". Before installation on the basis of the center line of the draw all and made on the "center the board" marked the impact point of tag, as the middle line of the benchmark when installation.
 Hoisting before dealing with ball mill for full acceptance of the parts, handle in time when problems found.
 1, the specific requirements of the main bearing part see main bearing parts assembly drawing.
 2, barrel part see rotary part assembly drawing.
 3, transmission part see part of the assembly drawing.
 4, overall relative position see assembly drawing.

Our Services:
 Pre-sale services: enthusiasm
 We provide you with the process plan, process flow design and manufacturer equipment according to your special demand.
 Sale services: servant
 Send technicians to the job site for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
 After-sale services: faithfulness
 To establish long term friendship, we will regularly pay return visit to customers.
 In addition, we provide one-year warranty to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.

•
