Suspended Conveyor Belt Magnetic Separator

Product Details: Name: Suspended Conveyor Belt Magnetic Separator Country: China Usage: Applicable to eliminate the powder or massive waste iron from the nonmagnetic material C lassification : Electromagnetic Separator Parameters: Introduction： Suspended Conveyor Belt Magnetic Separator is...

Send Inquiry

Name: Suspended Conveyor Belt Magnetic Separator
Country: China
Usage: Applicable to eliminate the powder or massive waste iron from the nonmagnetic material
Classification: Electromagnetic Separator

Parameters:

Model	Cooling method	Applicable bandwidth （MM）	Rated height of suspension(MM)	Excitation power(KW)	Magnetic induction of Rated height(MT)	Drive motor power(KW)	Main dimensions						Weight (KG)
Model	Cooling method	Applicable bandwidth （MM）	Rated height of suspension(MM)	Excitation power(KW)	Magnetic induction of Rated height(MT)	Drive motor power(KW)	A	B	C	D	E	F	Weight (KG)
RCDD-5	Self-cooled	500	150	≤2	≥70	1.5	2370	958	732	905	730	516	920
RCDD-6		650	200	≤3	≥70	1.5	2475	1104	732	955	873	486	1230
RCDD-8		800	250	≤4.5	≥70	2.2	2675	1297	752	1000	1010	537	1760
RCDD-10		1000	300	≤6	≥70	3	2780	1550	950	1200	1210	650	2850
RCDD-12		1200	350	≤9.5	≥70	3	3085	1673	1046	1400	1450	761	4020
RCDD-14		1400	400	≤12	≥70	4	3420	1972	1160	1700	1650	841	5500
RCDD-16		1600	450	≤14.5	≥70	5.5	3950	2300	930	1850	1850	945	7790
RCDD-18		1800	500	≤18	≥70	7.5	4450	2600	1060	1900	2050	1393	11800
RCDD-20		2000	550	≤23.5	≥70	7.5	4600	2720	1120	1900	2250	1337	13000

Introduction：
Suspended Conveyor Belt Magnetic Separator is self-unloading type magnet separator in long-term system. It is added platform, iron removing belt and etc, which is suspended over the belt conveyer. Through the conveyance of the iron unloading belt, the separator will auto discarge the iron magnetic articles which are absorbed by the magnet into the iron collecting box. Thus removing the iron magnetic articles is gained. Which is the one of the most common used types of separator.

Application:
It is used to eliminate the powder or massive waste iron from the nonmagnetic material. The inner adopts the special resin to cast with wholly sealed structure. It features with deep revealed magnetic depth, strong magnetic force, dust-protection and rain-protection, erosion wearing and so on. It can be operated in the harsh environment.

Features:
1 By using the computer simulation magnetic circuit design, through magnetic depth, magnetic force is strong.
2 Special duct design, coil heat faster, low temperature.
3 Coil adopts advanced insulation processing technology, with its anti corrosive.
4 Automatic discharging iron. Easy maintenance, belt automatic correction
5 Product good compatibility, complete function.

Our Services:
Pre-sale services: enthusiasm
We provide you with the process plan, process flow design and manufacturer equipment according to your special demand.
Sale services: servant
Send technicians to the job site for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
After-sale services: faithfulness
To establish long term friendship, we will regularly pay return visit to customers.
In addition, we provide one-year warranty to make sure the product runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.

More:
As a professional manufacturer and designer of Suspended Conveyor Belt Magnetic Separator for more than 50 years, we can offer various kinds of products with advanced mechanical equipments and experienced technical workers that we can provide the product on top quality and best price. The product will be shipping from China factory directly to your offered address. We are confident to be the best supplier in China.
